Running kagent on a kind Cluster with a Local vLLM + Qwen3 Backend

By Sebastian Maniak

Most kagent walkthroughs assume you’re pointing at OpenAI or Anthropic. But what if you want to run the entire stack locally — agents, controller, and the model — with zero tokens leaving your lab?

That’s exactly what this demo does. We’ll spin up a throwaway kind cluster, install kagent with all the built-in agents disabled, and wire its default provider to a self-hosted vLLM endpoint serving Qwen/Qwen3.6-35B-A3B-FP8. From there you can build agents from a clean slate — no cloud LLM, no API bill, no data egress.

Why This Setup?

A few reasons this combo is worth your time:

• Fully local inference — the model runs on your own GPU (in my case a DGX Spark), so prompts and cluster data never leave the building.
• Disposable environment — kind means the whole cluster is one docker container. Break it, delete it, recreate it in 30 seconds.
• Clean slate — disabling the bundled agents means kagent comes up as a bare control plane. You decide which agents exist, instead of inheriting eight of them.
• OpenAI-compatible — vLLM exposes the standard /v1 API, so kagent’s openAI provider talks to it with nothing more than a baseUrl override.

Architecture

┌─────────────────────────────────────┐
│  kind cluster (kagent-demo)          │
│                                      │
│   ┌────────────────────────────┐     │
│   │ kagent control plane        │     │
│   │ (controller + UI)           │     │
│   │  provider: openAI           │     │
│   └──────────────┬─────────────┘     │
│                  │ OpenAI /v1 API     │
└──────────────────┼────────────────────┘
                   │  (baseUrl override)
                   ▼
        ┌────────────────────────┐
        │  vLLM server            │
        │  Qwen3.6-35B-A3B-FP8    │
        │  DGX Spark · :8000/v1   │
        └────────────────────────┘

The cluster runs everything except the model. The model lives on a separate box (the DGX Spark) and is reached over the network at http://172.16.10.173:8000/v1. kagent doesn’t care that it’s not OpenAI — as far as it’s concerned, it’s just an OpenAI-compatible endpoint.

Prerequisites

• kind
• kubectl
• helm
• A reachable vLLM endpoint serving the Qwen/Qwen3.6-35B-A3B-FP8 model (see the DGX Spark config at the end)

Step 1: Create the kind Cluster

One command and you’ve got a single-node Kubernetes cluster running inside Docker:

kind create cluster --name kagent-demo

Step 2: Install the kagent CRDs

This installs the Custom Resource Definitions kagent depends on, and — thanks to --create-namespace — creates the kagent namespace that every later step relies on. Run it first.

helm install kagent-crds oci://ghcr.io/kagent-dev/kagent/helm/kagent-crds \
  --namespace kagent --create-namespace

Step 3: Create the vLLM API Key Secret

kagent’s openAI provider expects an API key, even when the backend doesn’t enforce one. vLLM typically ignores the key, so any non-empty value works:

kubectl create secret generic kagent-vllm \
  -n kagent \
  --from-literal=VLLM_API_KEY=dummykey

The kagent namespace already exists from Step 2, so this secret lands in the right place. Order matters here.

Step 4: Install kagent — Without the Default Agents

This is the interesting part. The kagent chart ships a set of built-in agents (k8s, helm, istio, cilium, kgateway, promql, observability, argo-rollouts). For this demo we disable all of them so we can build our own agents from scratch. We also point the default provider at our vLLM/Qwen endpoint — just adjust config.baseUrl to match your own server.

helm install kagent oci://ghcr.io/kagent-dev/kagent/helm/kagent \
  --namespace kagent \
  --set k8s-agent.enabled=false \
  --set helm-agent.enabled=false \
  --set istio-agent.enabled=false \
  --set promql-agent.enabled=false \
  --set observability-agent.enabled=false \
  --set argo-rollouts-agent.enabled=false \
  --set cilium-debug-agent.enabled=false \
  --set cilium-manager-agent.enabled=false \
  --set cilium-policy-agent.enabled=false \
  --set kgateway-agent.enabled=false \
  --set grafana-mcp.enabled=false \
  --set querydoc.enabled=false \
  --set providers.default=openAI \
  --set providers.openAI.provider=OpenAI \
  --set-string providers.openAI.model="Qwen/Qwen3.6-35B-A3B-FP8" \
  --set providers.openAI.apiKeySecretRef=kagent-vllm \
  --set providers.openAI.apiKeySecretKey=VLLM_API_KEY \
  --set-string providers.openAI.config.baseUrl="http://172.16.10.173:8000/v1"

A few things worth calling out:

Step 5: Verify the Control Plane

Check that the control-plane pods come up and that no default agents were created:

kubectl get pods -n kagent
kubectl get agents -n kagent   # should be empty

If get agents returns nothing, the disable flags did their job. 🎉

The kagent UI

Once the control plane is healthy, open the kagent UI. The Models view confirms the provider wiring — you should see a default-model-config pointing at OpenAI as the provider, the Qwen model ID, the kagent-vllm API key secret, and your vLLM baseUrl under provider parameters:

The Agents view starts empty — exactly what we wanted. Here I’ve created a single test agent from scratch, running on the local OpenAI (Qwen/Qwen3.6-35B-A3B-FP8) model:

From here the cluster is yours. Create agents, attach MCP tool servers, and every inference call routes to your local Qwen model instead of a cloud API.

Cleanup

When you’re done, tear the whole thing down with a single command:

kind delete cluster --name kagent-demo

No leftover namespaces, no orphaned resources — the entire cluster was a Docker container, and now it’s gone.

Bonus: The vLLM Server on DGX Spark

For completeness, here’s the exact docker run I use to serve Qwen3.6 on my DGX Spark. This is the endpoint kagent’s baseUrl points at:

docker run -d --name vllm-qwen36 \
  --restart always \
  --runtime nvidia --gpus all \
  --network host --ipc host --shm-size 96g \
  -v ~/.cache/huggingface:/root/.cache/huggingface \
  vllm/vllm-openai:cu130-nightly \
  --model Qwen/Qwen3.6-35B-A3B-FP8 \
  --host 0.0.0.0 --port 8000 \
  --gpu-memory-utilization 0.85 \
  --max-model-len 262144 \
  --max-num-seqs 16 \
  --max-cudagraph-capture-size 256 \
  --reasoning-parser qwen3 \
  --enable-auto-tool-choice \
  --tool-call-parser qwen3_coder

Highlights that make this work well for agentic workloads:

• --enable-auto-tool-choice + --tool-call-parser qwen3_coder — lets the model emit proper tool calls, which is essential for kagent agents that invoke MCP tools.
• --reasoning-parser qwen3 — separates the model’s reasoning trace from its final answer.
• --max-model-len 262144 — a generous 256K context window, plenty of room for long agent conversations and tool outputs.
• --gpu-memory-utilization 0.85 — leaves a little headroom on the GPU.

Wrapping Up

In under ten minutes you’ve got a disposable Kubernetes cluster running kagent with a fully local LLM backend — no cloud provider, no API key that matters, no data leaving your network. Because the model speaks the OpenAI API, kagent didn’t need any special integration: just a baseUrl swap.

This is my go-to scratchpad for prototyping agents before promoting them to a real cluster. The kind cluster is cheap to create and free to destroy, and the Qwen3.6 model on the DGX Spark is fast enough to make the loop feel interactive.

Next up: building a real agent on top of this and wiring it to MCP tool servers. Stay tuned.
